Zebra MC9500-K Wireless Rugged Handheld Mobile Computer

Zebra MC9500-K Premium Industrial-Class Mobile Computer

The MC9500-K raises the bar for premier rugged mobile computing, incorporating breakthrough ergonomic design and features to support the most demanding field mobility applications. Truly in a class of its own, this groundbreaking device is as different on the inside as it is on the outside.

Building on the MC9000 Series, the MC9500-K delivers a more rugged design, more data capture options, true WAN technology independence and application flexibility through customer-swappable WAN subsystems and keypads, more processing power and a game-changing approach to battery and backroom management — all in a lighter, sleeker and easier-to-use form factor.

The next evolution in rugged design, ergonomics, features, functionality and performance
The MC9500-K Series leverages the flagship features and functionality of Zebra's signature MC9000 Series rugged mobile computers, while introducing many new capabilities defined through extensive research and testing in logistics, parcel/post, direct store delivery (DSD), field service, public safety and sales force automation applications in some of the world’s leading organizations. The result is a device that is as different on the inside as it is on the outside — a groundbreaking product with an unsurpassed feature set that takes rugged mobile computing innovation to a new level. With the MC9500-K Series, you can simply expect more: a more rugged design, more data capture options, more intelligence, more processing power and better ergonomics, all in a sleeker, lighter and easier-to-use form factor that offers true carrier independence as well as a completely new approach to accessories, battery and backroom management.

• Zebra MAX Rugged: Next generation rugged design: industry leading drop and tumble tests, IP67 sealing, Monocoque housing and integrated internal antennas (WWAN, WLAN and GPS); meets and exceeds applicable MIL-STD and IEC specifications for drop, tumble, sealing and other environment parameters
  Premier rugged specifications enable dependable year-round use in nearly any environment, including exposure to heat, cold, humidity, dust, immersion in water, drops and bumps

•  Next generation ergonomic design
  Sleeker, smaller, easier-to-grip rugged form factor delivers a new level of comfort and easy one-handed operation for key-based applications

• Zebra MAX FlexWAN: Customer swappable broadband 3.5G GSM HSDPA and 3.5G CDMA-EVDO Rev A
  High performance simultaneous wireless broadband voice and data anywhere in the world (where supported by carrier); best-in-class 3G speed with a connection to most carriers in the world; customer configurable WAN capability allows companies to easily and cost-effectively support multiple carriers — and ensure each worker has the best possible coverage

• Zebra MAX Keypad: Modular field swappable keypad options with new ergonomics — alpha primary, numeric telephony, numeric calculator, and full alphanumeric
  Flexibility to standardize on one device yet meet diverse user and application needs; well-designed keypads with core keys positioned to enable comfortable one-handed operation; function keys and programmable trigger keys simplify day-to-day processes

• 3.7 inch color high resolution polycarbonate VGA display (640 x 480) with digitizer and backlight
  Largest display available in this device category; supports display of high resolution images, including video and maps; provides best-in-class impact resistance

• Mobility Platform Architecture (MPA) 2.0
  Provides the latest best-in-class technology architecture; preserves existing application investments by enabling easy and cost-effective porting of applications from other Zebra mobile computers

• Next generation performance: powerful Marvell @ 806 MHz microprocessor, larger memory footprint and a user accessible micro-SD card
  Provides superior performance for even the most demanding multimedia applications with the fastest processor in this device category and a robust memory architecture

• Zebra MAX Sensor: Interactive Sensor Technology (IST)
  Enables leading edge motion-based applications, including dynamic screen orientation, power management and free-fall event logging

• Zebra MAX Backroom Management: game-changing backroom management through a one-of-a-kind Universal Accessory System
  New modular design reduces the capital and operational costs in the backroom related to batteries, cradles, battery chargers, cables and other accessories; form-factor agnostic cradling is compatible with future generations of Zebra mobile computers, providing superior future-proofing and investment protection

• Zebra MAX Battery: high-capacity battery with unique, industry-first battery information indicators
  Enables battery to "report" its own status — state of charge and state of overall battery health; enables more cost-effective management of the battery pool; ensures users start the day with a battery capable of providing full-shift support for improved productivity
